100uF 50V General Purpose Electrolytic Capacitor
100uF 50V General Purpose Electrolytic Capacitor
Regular price
$0.04 USD
Regular price
Sale price
$0.04 USD
Unit price
/
per
Shipping calculated at checkout.
300 in stock
Couldn't load pickup availability
Condition: New
Brand: NICHICON
MPN: UVR1H101MPD1TA
MPN Xref:UVR1H101MPD1TA, 647-UVR1H101MPD1TA, UVR1H101MPD1TA-ND, NICH-0063067, E4776963, 55K2119
This is a general purpose electrolytic capacitor with a capacitance of 100uF and voltage rating of 50V. It has a radial lead type and is suitable for various applications.
Parts of this page were generated by an AI
WARNING: Products on this website can expose you to chemicals including Lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
All orders are subject to inventory availability and approval. We are not responsible or liable for errors in the listings.
Brand: NICHICON
MPN: UVR1H101MPD1TA
MPN Xref:UVR1H101MPD1TA, 647-UVR1H101MPD1TA, UVR1H101MPD1TA-ND, NICH-0063067, E4776963, 55K2119
This is a general purpose electrolytic capacitor with a capacitance of 100uF and voltage rating of 50V. It has a radial lead type and is suitable for various applications.
| Category | Capacitors |
| Series | VR |
| Package | Tape & Box (TB) |
| Part Status | ?20% |
| Tolerance | ?20% |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 85?C |
| Operating Temperature | Polar |
| Polarization | - |
| Ratings | - |
| Applications | General Purpose |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.453" (11.50mm) |
| Height - Seated (Max) | - |
| Surface Mount Land Size | - |
| Mounting Type | Radial, Can |
| Package / Case | 100 ?F |
| Capacitance | 100 uF |
| Voltage - Rated | 260 mA @ 120 Hz |
| Ripple Current @ Low Frequency | 260 mA @ 120 Hz |
| Manufacturer Product Number | UVR1H101MPD1TA |
| Description | CAP ALUM 100UF 20% 50V RADIAL |
| Detailed Description | 100 ?F 50 V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85?C |
| Product Status | Not For New Designs |
| Ripple Current @ High Frequency | 390 mA @ 10 kHz |
| Voltage Rating DC | 50 V |
| Product Category | Aluminium Electrolytic Capacitors - Leaded |
| Alternate Part No. | 647-UVR1H101MPD1TA |
| Dissipation Factor DF | 0.12 |
| Leakage Current | 150 uA |
| Dimensions | 8 mm Dia. x 11.5 mm L |
| Packaging | Reel |
| Manufacturer Part No. | UVR1H101MPD1TA |
| Ripple Current | 260 mA |
| Load Life | 2000 h |
| Maximum Operating Temperature | + 85 C |
| Case Length | 11.5 mm |
| Case Diameter | 8 mm |
| Product | General Purpose Electrolytic Capacitors |
| Termination Style | Radial |
| capacitance | 100 uf |
| voltage | 50 vdc |
| tolerance | 20% |
| temperature | 85 |
| lead type | radial |
| package | AMMO 1K |
| item per pack | 1 |
| Capacitance Range | 100 to 999 uF |
| Element Material | Aluminum Electrolytic |
