Capacitor Aluminum 56uF 50V Radial

Capacitor Aluminum 56uF 50V Radial

Regular price $0.02 USD
Regular price Sale price $0.02 USD
Sale Sold out
Shipping calculated at checkout.

399 in stock

Condition: New
Brand: Nichicon
MPN: UPW1H560MED
MPN Xref:UPW1H560MED, 70187338, 493-1897-ND, 647-UPW1H560MED, 55K0278, 7152830P, 7152830, NICH-0046088

56 ?F 50 V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105?C
Manufacturer Product Number UPW1H560MED
Description CAP ALUM 56UF 20% 50V RADIAL
Detailed Description 56 ?F 50 V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105?C
Category Capacitors
Series UPW Series
Package Bulk
Product Status Obsolete
Capacitance 56?F
Tolerance ?20%
Voltage - Rated 50 V
ESR (Equivalent Series Resistance) -
Lifetime @ Temp. 2000 Hrs @ 105?C
Operating Temperature -55?C ~ 105?C
Polarization Polar
Ratings -
Applications General Purpose
Ripple Current @ Low Frequency 108 mA @ 120 Hz
Ripple Current @ High Frequency 360 mA @ 100 kHz
Impedance 400 mOhms
Lead Spacing 2.5 mm
Size / Dimension 0.248" Dia (6.30mm)
Height - Seated (Max) 0.591" (15.00mm)
Surface Mount Land Size -
Mounting Type PCB Mount
Package / Case Radial, Can
Gross Weight 0.0016 lbs
Packaging Bulk
Ripple Current 360 mA
Voltage Rating DC 50 V
Leakage Current 84 uA
Maximum Operating Temperature + 105 C
Type Extremely Low Impedance, High Reliability
Load Life 2000 h
Case Diameter 6.3 mm
Product Low Impedance Electrolytic Capacitors
Termination Style Radial
Manufacturer Part No. UPW1H560MED
Case Length 15 mm
Dimensions 6.3 mm Dia. x 15 mm L
Dissipation Factor DF 0.1
Alternate Part No. 647-UPW1H560MED
Product Category Aluminium Electrolytic Capacitors - Leaded
Type of capacitor electrolytic
Kind of capacitor low ESR
Capacitor application switching power supplies
Mounting THT
Operating voltage 50V DC
Body dimensions ?6.3x15mm
Terminal pitch 2.5mm
Service life 2000h
Operating temperature -55...105?C
Capacitors series UPW
Operating current 360mA
Part status Obsolete
Capacitance Range 1 to 99 uF
Case Size Dia. 0.248 x L 0.591 in ; Dia. 6.3 x L 15 mm
Configuration Radial ; Can
Element Material Aluminum Electrolytic
Minimum Operating Temperature -55 C
Termination Through Hole
Voltage Rating 50 VDC
