100?F 50V Aluminum Electrolytic Capacitor - Radial
100?F 50V Aluminum Electrolytic Capacitor - Radial
Regular price
$0.06 USD
Regular price
Sale price
$0.06 USD
Unit price
/
per
Shipping calculated at checkout.
48 in stock
Couldn't load pickup availability
Condition: New
Brand: Nichicon
MPN: UHE1H101MPD
MPN Xref:UHE1H101MPD, 493-1605-ND, NICH-0057276, 647-UHE1H101MPD, 23K7790, 4910276
This is a 100?F 50V radial aluminum electrolytic capacitor with a tolerance of ?20%. It has a low ESR and is suitable for general purpose applications. It has a service life of 7000 hours at 105?C and operates at temperatures ranging from -40?C to 105?C. The capacitor is polarized and has a diameter of 8mm and a height of 11.5mm.
Parts of this page were generated by an AI
WARNING: Products on this website can expose you to chemicals including Lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
All orders are subject to inventory availability and approval. We are not responsible or liable for errors in the listings.
Brand: Nichicon
MPN: UHE1H101MPD
MPN Xref:UHE1H101MPD, 493-1605-ND, NICH-0057276, 647-UHE1H101MPD, 23K7790, 4910276
This is a 100?F 50V radial aluminum electrolytic capacitor with a tolerance of ?20%. It has a low ESR and is suitable for general purpose applications. It has a service life of 7000 hours at 105?C and operates at temperatures ranging from -40?C to 105?C. The capacitor is polarized and has a diameter of 8mm and a height of 11.5mm.
| Weight (lbs) | (0.0025) |
| Case Style | Radial |
| Voltage (V) | 50 |
| Polarity | Polar |
| Height (mm) | 11.5 |
| Type | Electrolytic |
| Capacitance (uF) | 100 |
| Diameter (mm) | 8 |
| Temperature (deg C) | 105 |
| Category | Capacitors |
| Series | Bulk |
| Package | Active |
| Part Status | ?20% |
| Tolerance | ?20% |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | -40?C ~ 105?C |
| Operating Temperature | Polar |
| Polarization | - |
| Ratings | - |
| Applications | 0.138" (3.50mm) |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.453" (11.50mm) |
| Height - Seated (Max) | - |
| Surface Mount Land Size | - |
| Mounting Type | Radial, Can |
| Package / Case | 100 ?F |
| Capacitance | 100?F |
| Voltage - Rated | 170 mOhms |
| Impedance | 170 mOhms |
| Ripple Current @ Low Frequency | 555 mA @ 100 kHz |
| Manufacturer Product Number | UHE1H101MPD |
| Description | CAP ALUM 100UF 20% 50V RADIAL |
| Detailed Description | 100 ?F 50 V Aluminum Electrolytic Capacitors Radial, Can 7000 Hrs @ 105?C |
| Product Status | Not For New Designs |
| Ripple Current @ High Frequency | 555 mA @ 100 kHz |
| Type of capacitor | electrolytic |
| Kind of capacitor | low ESR |
| Mounting | THT |
| Operating voltage | 50V DC |
| Body dimensions | ?8x11.5mm |
| Terminal pitch | 3.5mm |
| Service life | 7000h |
| Operating temperature | -40...105?C |
| Capacitors series | UHE |
| Operating current | 555mA |
