TVS Diode 5.8VWM 10.5VC DO204AC

Condition: New
Brand: Littelfuse Inc.
MPN: P6KE6.8A
MPN Xref:P6KE6.8A, 1703028, P6KE6.8AOS-ND, 21969964, LITT-0031133, 72K7307, 91R0579, WI-569-4-23108, LITT-0010542

TVS DIODE 5.8VWM 10.5VC DO204AC - 10.5V Clamp 58.1A Ipp Through Hole (DO-15) TVS Diode

Manufacturer	LITTELFUSE
Type of diode	TVS
Peak pulse power dissipation	600W
Max. off-state voltage	5.8V
Breakdown voltage	6.8V
Max. forward impulse current	58.1A
Semiconductor structure	unidirectional
Tolerance	?5%
Case	DO15
Mounting	THT
Leakage current	1mA
Kind of package	reel,
Features of semiconductor devices	glass passivated
Manufacturer Product Number	P6KE6.8A
Description	TVS DIODE 5.8VWM 10.5VC DO204AC
Manufacturer Standard Lead Time	14 Weeks
Detailed Description	10.5V Clamp 58.1A Ipp Tvs Diode Through Hole DO-204AC (DO-15)
Category	Circuit Protection
Series	P6KE
Package	Tape & Reel (TR)
Product Status	Active
Type	TVS
Unidirectional Channels	1
Voltage - Reverse Standoff (Typ)	5.8V
Voltage - Breakdown (Min)	6.45V
Voltage - Clamping (Max) @ Ipp	10.5V
Current - Peak Pulse (10/1000?s)	58.1A
Power - Peak Pulse	600W
Power Line Protection	No
Applications	General Purpose
Capacitance @ Frequency	-
Operating Temperature	-55?C ~ 175?C (TJ)
Mounting Type	Through Hole
Package / Case	DO-204AC, DO-15, Axial
Supplier Device Package	DO-204AC (DO-15)
Package/Case	DO-15
Product Categories	TVS Diodes - Transient Voltage Suppressors
RoHs Status	Lead free/RoHS Compliant
In-stock	42977
Breakdown Voltage	6.45 V
Clamping Voltage	10.5 V
Configuration	Single
Current, Ratings	58.1 A
Diameter	3.6 mm
Dimensions	3.6 mm Dia. x 3.6 (Max) mm W x 7.6 mm L
ESD Protection	Yes
ESD Voltage	15 (Air), 8 (Contact) kV
For Use With	Data/Comm, Industrial Equipment
Forward Current	58.1 A
Leakage Current	1000 μA
Length	0.299 in
Maximum Junction Temperature	175 °C
Maximum Operating Temperature	+150 °C
Minimum Operating Temperature	-55 °C
Number of Pins	2
Package Type	DO-15
Peak Current	58.1 A
Power Dissipation	600 W
Primary Type	Diodes
Product Header	P6KE Series Unidirectional Transient Voltage Suppression Diode
Reverse Current	1000 uA @ 5.80 V
Reverse Standoff Voltage	5.8 V
Stand Off Voltage	5.8 V
Suppressor Type	Voltage
Surge Current	100 A
Temperature Operating Range	-55 to +150 °C
Termination	Lead Wires
Test Current	10 mA
Peak Surge Current	57 A
Brand	Littelfuse
Operating Voltage	5.8 V
Part # Aliases	P6KE6.8A.
Product Category	TVS Diodes - Transient Voltage Suppressors
Mounting Style	Through Hole
Polarity	Unidirectional
Peak Pulse Power Dissipation	600 W
Alternate Part No.	576-P6KE6.8A
Termination Style	Axial
Manufacturer Part No.	P6KE6.8A
Packaging	Reel
