Polymeric PTC Resettable Fuse 60V 1.1A

Condition: New
Brand: LITTELFUSE
MPN: 60R110XMR
MPN Xref:60R110XMR, 39X0725, LITT-0035615, 60R110, F1993TB-ND, 272639, LITT-0065778, F1993CT-ND, FUSE6171

Polymeric PTC Resettable Fuse 60V 1.1A Through Hole Radial

Manufacturer Product Number	60R110XMR
Description	PTC RESET FUSE 60V 1.1A RADIAL
Manufacturer Standard Lead Time	15 Weeks
Detailed Description	Polymeric PTC Resettable Fuse 60V 1.1 A Ih Through Hole Radial, Disc
Category	Circuit Protection
Series	POLY-FUSE?, 60R
Package	Cut Tape (CT)
Product Status	Active
Type	Polymeric
Voltage - Max	60V
Current - Hold (Ih) (Max)	1.1 A
Current - Trip (It)	2.2 A
Current - Max	40 A
Time to Trip	8.2 s
Resistance - Initial (Ri) (Min)	150 mOhms
Resistance - Post Trip (R1) (Max)	380 mOhms
Operating Temperature	-40?C ~ 85?C
Ratings	-
Mounting Type	Through Hole
Package / Case	Radial, Disc
Size / Dimension	0.512" Dia x 0.122" T (13.00mm x 3.10mm)
Height - Seated (Max)	0.717" (18.20mm)
Thickness (Max)	-
Lead Spacing	5.1 mm
Approval Agency	cURus, TUV
Package/Case	SOP-DIP
Product Categories	PTC Resettable Fuses
RoHs Status	Rohs
In-stock	310
Mounting Style	Through Hole
Termination Style	Radial
Trip Current	2.2 A
Operating Temperature Range	- 40 C to + 85 C
Current Rating (Max)	40 A
Dimensions	18.2 mm L x 3.1 mm H x 13 mm D
Maximum Voltage	60 VDC
Packaging	Ammo Pack
Factory Pack Quantity	1000
Manufacturer Part No.	60R110XMR
Hold Current	1.1 A
Current Rating - Max	40 A
Alternate Part No.	576-60R110XMR
Product Category	Resettable Fuses - PPTC
Resistance	380 mOhms
