This is a SLO-BLO 3AG type glass fuse with a current rating of 6.3A and a voltage rating of 250VAC. It has a time delay characteristic and is suitable for use in various applications.
Manufacturer Part Number
031306.3VXP
Item Number
31306.3P
Product Series
313
Material
Glass
Current Rating
6.3 A
Voltage (AC)
250 VAC
Voltage (DC)
250 VDC
Characteristic
Time Delay
Package Type
Cartridge
Interrupt Rating
10 kA
Trip Indicator
No
Alarm Contact
No
Diameter (mm)
6.35 mm
Body Length (mm)
31.75 mm
Approvals
CE, CSA, UL
RoHS
Yes
Net Weight
0 lbs
Gross Weight
0 lbs
Description:
SLO-BLO 3AG TYPE GLASS FUSE
MFG Part #:
31306.3P
UPC:
07945892356
Standard Pack:
Order QTY must be in multiples of 5
Amperage Rating
6.3 A
Body Size
1/4 in Dia x 1-1/4 in L
Body Type
Cartridge
Class
K5
Indicating/Non-Indicating
Non-Indicating
Mounting Type
Holder
Response Time
4 hr, 1 hr, 5 to 30 s
Series
313
Terminal Type
Axial Lead
Type
Time Delay
Voltage Rating
250 VAC
Diameter
0.250 in
Opening
Time-Delay, Slow-Blow
Volts AC
32
Mounting
Cartridge
Length
1.250 in
Amps
6.300
Standards
California Proposition 65
Interrupt Rating DC
300, 10 kA
