Obsolete PNP Transistor - 800mA/45V/1.5W/260MHz - TO-92-3
Obsolete PNP Transistor - 800mA/45V/1.5W/260MHz - TO-92-3
Regular price
$0.09 USD
Regular price
Sale price
$0.09 USD
Unit price
/
per
53 in stock
Condition: New
Brand: ON Semiconductor
MPN: BC327-40ZL1G
MPN Xref:BC327-40ZL1G, 2317541, 863-BC327-40ZL1G, BC327-40ZL1GOSCT-ND, 17102700, ONSM-0039097, 26K3394, 605016, BC327-40ZL1GOSTB-ND
This is a PNP transistor with a maximum current collector of 800 mA and a maximum voltage breakdown of 45 V. It has a power rating of 1.5 W and a frequency transition of 260 MHz. The transistor is obsolete and has a temperature range of -55°C to 150°C.
Parts of this page were generated by an AI
WARNING: Products on this website can expose you to chemicals including Lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
All orders are subject to inventory availability and approval. We are not responsible or liable for errors in the listings.
Brand: ON Semiconductor
MPN: BC327-40ZL1G
MPN Xref:BC327-40ZL1G, 2317541, 863-BC327-40ZL1G, BC327-40ZL1GOSCT-ND, 17102700, ONSM-0039097, 26K3394, 605016, BC327-40ZL1GOSTB-ND
This is a PNP transistor with a maximum current collector of 800 mA and a maximum voltage breakdown of 45 V. It has a power rating of 1.5 W and a frequency transition of 260 MHz. The transistor is obsolete and has a temperature range of -55°C to 150°C.
Package/Case | TO-92-3 |
Product Categories | Bipolar Transistors |
RoHs Status | Green |
Life Cycle | Obsoleted |
In-stock | 30000 |
Collector Emitter Saturation Voltage | - 0.7 V |
Maximum DC Collector Current | 0.8 A |
Gain Bandwidth Product fT | 260 MHz |
DC Collector/Base Gain hfe Min | 250 at 100 mA at 1 V |
Maximum Operating Temperature | + 150 C |
Mounting Style | Through Hole |
Package / Case | TO-92-3 (TO-226) |
Continuous Collector Current | - 0.8 A |
Maximum Power Dissipation | 625 mW |
Minimum Operating Temperature | - 55 C |
Packaging | Ammo |
Factory Pack Quantity | 2000 |
Category | Discrete Semiconductor Products |
Mfr | onsemi |
Series | - |
Package | Cut Tape (CT) |
Product Status | Obsolete |
Transistor Type | PNP |
Current - Collector (Ic) (Max) | 800 mA |
Voltage - Collector Emitter Breakdown (Max) | 45 V |
Vce Saturation (Max) @ Ib, Ic | 700mV @ 50mA, 500mA |
Current - Collector Cutoff (Max) | 100nA |
DC Current Gain (hFE) (Min) @ Ic, Vce | 250 @ 100mA, 1V |
Power - Max | 1.5 W |
Frequency - Transition | 260MHz |
Operating Temperature | -55?C ~ 150?C (TJ) |
Mounting Type | Through Hole |
Supplier Device Package | TO-92 (TO-226) |
Base Product Number | BC327 |
