Fairchild Semiconductor Diode Configuration Stud Cathode Single 3A 200V

Fairchild Semiconductor Diode Configuration Stud Cathode Single 3A 200V

Regular price $0.07 USD
Regular price Sale price $0.07 USD
Sale Sold out
Shipping calculated at checkout.

1025 in stock

Condition: New
Brand: ON SEMI
MPN: 1N5402
MPN Xref:1N5402, DLGL5653, 81017, TSC1-0000339, 512-1N5402, DLGL5602, 70015975, 1N5402FSTR-ND, 9565078

This diode configuration features a stud cathode and is single-ended. It has a maximum forward current of 3A and a peak reverse repetitive voltage of 200V. The diode has a standard recovery speed and is suitable for switching applications. It is manufactured by Fairchild Semiconductor and is available in various package types.
Diode Configuration Stud Cathode
Number of Elements per Chip 1
Brand Fairchild Semiconductor
Package Type DO-201AD
Maximum Continuous Forward Current 3A
Mounting Type Through Hole
Diameter 5.6mm
Maximum Forward Voltage Drop 1V
Pin Count 2
Peak Non-Repetitive Forward Surge Current 200A
Diode Type Silicon Junction
Peak Reverse Repetitive Voltage 200V
Diode Technology Silicon Junction
Rectifier Type Switching
Category Discrete Semiconductor Products
Mfr onsemi
Series -
Package Bulk
Product Status Obsolete
Voltage - DC Reverse (Vr) (Max) 1 V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 1.2 V @ 3 A
Speed Standard Recovery >500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 200 nA @ 1 kV
Capacitance @ Vr, F -
Package / Case DO-201AA, DO-27, Axial
Supplier Device Package DO-201
Operating Temperature - Junction -50?C ~ 175?C
Base Product Number 1N5402
Part Status Active
Reverse Recovery Time (trr) 1.5 ?s
Package/Case DO-201
Product Categories Rectifiers
RoHs Status Lead free/RoHS Compliant
Life Cycle Obsoleted
In-stock 10000
Max Surge Current 200 A
Reverse Current IR 5 uA
Mounting Style Through Hole
Packaging Reel
Maximum Operating Temperature + 150 C
Minimum Operating Temperature - 55 C
Power Dissipation 6.25 W
Factory Pack Quantity 1250
Part # Aliases 1N5402_NL
