IC OPAMP JFET 4 Circuit 14DIP

IC OPAMP JFET 4 Circuit 14DIP

Regular price $0.29 USD
Regular price Sale price $0.29 USD
Sale Sold out
Shipping calculated at checkout.

50 in stock

Condition: New
Brand: TEXAS INSTRUMENTS
MPN: TL074IN
MPN Xref:TL074IN, 456422, 662607, TI01-0002735, 1470384, 296-7200-5-ND, 89K1721, 527968, 70013556

IC OPAMP JFET 4 Circuit 14DIP
Type of integrated circuit operational amplifier
Bandwidth 3MHz
Mounting THT
Number of channels 4
Case DIP14
Slew rate 13V/?s
Operating temperature 0...70?C
Voltage supply range ? 5...15V DC
Manufacturer Product Number TL074IN
Description IC OPAMP JFET 4 CIRCUIT 14DIP
Manufacturer Standard Lead Time 6 Weeks
Detailed Description J-FET Amplifier 4 Circuit 14-PDIP
Category Integrated Circuits (ICs)
Series -
Package Tube
Product Status Active
Amplifier Type J-FET
Number of Circuits 4
Output Type -
Slew Rate 13V/?s
Gain Bandwidth Product 3 MHz
Current - Input Bias 65 pA
Voltage - Input Offset 3 mV
Current - Supply 1.4mA (x4 Channels)
Voltage - Supply Span (Min) 10 V
Voltage - Supply Span (Max) 30 V
Operating Temperature -40?C ~ 85?C (TA)
Mounting Type Through Hole
Package / Case 14-DIP (0.300", 7.62mm)
Supplier Device Package 14-PDIP
Base Product Number TL074
Package/Case PDIP-14
Product Categories Op Amps
RoHs Status Rohs
Marking Code TL074IN
In-stock 0
Mounting Style Through Hole
Shutdown No
Maximum Operating Temperature + 85 C
Packaging Tube
Maximum Dual Supply Voltage +/- 18 V
Minimum Dual Supply Voltage +/- 3.5 V
Minimum Operating Temperature - 40 C
Factory Pack Quantity 25
Supply Current 10 mA
Technology BiFET
Voltage Gain dB 106.02 dB
Number of Channels per Chip 4
PRICED TO CLEAR Yes
Length 19.3mm
Typical Slew Rate 13V/µs
Typical Voltage Gain 106 dB
Power Supply Type Dual
Package Type PDIP
Width 6.35mm
Typical Input Voltage Noise Density 18nV/?Hz
Rail to Rail No
Height 4.57mm
Pin Count Pin Count
Dimensions Dimensions
Typical Gain Bandwidth Product Typical Gain Bandwidth Product
Typical Dual Supply Voltage Typical Dual Supply Voltage
Stock Stock
