Obsolete Discrete Semiconductor - 3.3V, 500mW

Obsolete Discrete Semiconductor - 3.3V, 500mW

Regular price $0.01 USD
Regular price Sale price $0.01 USD
Sale Sold out
Shipping calculated at checkout.

594 in stock

Condition: New
MPN: 1N5226B-TP
MPN Xref:1N5226B-TP, 1N5226B-TP**MULT1, MCC1-0000335, 833-1N5226B-TP, 1N5226B-TPTR-ND, 1N5226B-TPCT-ND

This product is an obsolete Discrete Semiconductor with a voltage of 3.3V and a power of 500mW. It has a current reverse leakage of 25 ?A @ 1V and a forward voltage of 1.1V @ 200mA. The operating temperature ranges from -55?C to 150?C and it is mounted through a hole.
Category Discrete Semiconductor Products
Mfr Micro Commercial Co
Series -
Package Tape & Reel (TR)
Product Status Obsolete
Voltage - Zener (Nom) (Vz) 3.3V
Power - Max 500mW
Impedance (Max) (Zzt) 28 Ohms
Current - Reverse Leakage @ Vr 25 ?A @ 1 V
Voltage - Forward (Vf) (Max) @ If 1.1 V @ 200 mA
Operating Temperature -55
Mounting Type Through Hole
Package / Case DO-204AH, DO-35, Axial
Supplier Device Package DO-35
Base Product Number 1N5226
Package/Case DO-35
Product Category Zener Diodes
Voltage Tolerance 5 %
Configuration Single
Voltage Temperature Coefficient - 0.07 %/C
Packaging Reel
Pd - Power Dissipation 500 mW
Maximum Reverse Leakage Current 25 uA
Mounting Style Through Hole
Maximum Operating Temperature + 150 C
Vz - Zener Voltage 3.3 V
Zz - Zener Impedance 28 Ohms
Alternate Part No. 833-1N5226B-TP
Manufacturer Part No. 1N5226B-TP
Minimum Operating Temperature - 55 C
Base Part Number 1N5226
Lead Free Status / RoHS Status RoHS Compliant
Manufacturer Part Number 1N5226B-TP
Manufacturer Standard Lead Time 14 Weeks
Standard Package 10,000
Alternate Parts 1N5226
