PH Series Natural Color Connector - 3 Positions, 2mm Pitch

Condition: New
Brand: JST
MPN: PHR-3
MPN Xref:PHR-3, 8201475, 455-1126-ND, 3616198, 106293, 14301981, 3531311, 113332, JST1-0012430

This natural color PH series connector is a receptacle type connector with crimp contact termination. It has 3 positions and a pitch of 0.079". The connector is a circular type with detent lock fastening and is rated for AC/DC2 current. It meets UL/TUV/CSA standards.

Color	Natural
Connector	plug
Type of connector	wire-board
Kind of connector	female
Connector series	PH
Contacts pitch	2mm
Number of pins	3
Connector variant	w/o contacts
Mechanical mounting	for cable
Rated voltage	100V
Current rating	2A
Connector pinout layout	1x3
Series	PH
Packaging	Bulk
Mounting Type	Free Hanging (In-Line)
Features	-
Connector Type	Receptacle
Contact Termination	Crimp
Number of Positions	3
Pitch	0.079" (2.00mm)
Number of Rows	1
Contact Type	Female Socket
Row Spacing	-
Fastening Type	Detent Lock
Connector Shape	Circular Type
Allowable Current(A)	AC/DC2
Representative Standard	UL / TUV / CSA
