This product is an active, automotive-grade resistor with a resistance of 453 Ohms and a tolerance of ±1%. It is a thick film resistor in an 0805 package designed for automotive applications and compliant with the AEC-Q200 standard. The operating temperature range is -55°C to 155°C. It comes in tape & reel packaging and has a power rating of 0.125W (1/8W).
Resistors
Series
CRCW
Package
Tape & Reel (TR)
Product Status
Active
Resistance
453 Ohms
Tolerance
?1%
Power (Watts)
0.125W, 1/8W
Composition
Thick Film
Features
Automotive AEC-Q200
Temperature Coefficient
?100ppm/?C
Operating Temperature
-55?C ~ 155?C
Package / Case
0805 (2012 Metric)
Supplier Device Package
0805
Ratings
AEC-Q200
Size / Dimension
0.079" L x 0.049" W (2.00mm x 1.25mm)
Height - Seated (Max)
0.020" (0.50mm)
Number of Terminations
2
Failure Rate
-
Base Product Number
CRCW0805
Category
Resistors
