Mini-Fit Jr. Plug Type Housing

Mini-Fit Jr. Plug Type Housing

Regular price $0.04 USD
Regular price Sale price $0.04 USD
Sale Sold out
Shipping calculated at checkout.

30 in stock

Condition: New
Brand: MOLEX
MPN: 39-01-4046
MPN Xref:39-01-4046, 022337, 78068798969, 39014046, MOLE-0043567, 9963529, 70191040, 538-39-01-4046, 18M8070

This Mini-Fit Jr. plug type housing is a low-profile, straight angle plug housing with 4 circuits and 4 contacts. It has a current rating of 13A and is made of nylon material. The operating temperature range is -40°C to +105°C. It is CSA, UL, and TUV approved.
Agency Approvals CSA ; UL ; TUV
Alternate Mfr Part Number 5559-04P3
Angle Straight
Color Natural
Current Rating 13 A
Family Name Mini-Fit Jr.
Gender Plug
Housing Material Nylon
Number of Circuits 4
Number of Contacts 4
Number of Rows 1
Operating Temperature -40 to +105 °C
Overall Length 0.81 "
Pin Spacing 0.165 in
Pitch 4.20 mm (0.165")
Primary Type Soft Shell
Product Header Mini-Fit Jr.™ Plug Type Housing
Series 5559 Series
Special Features Low-Halogen
Strain Relief Low Profile
Type Plug Housing
Pitch - Termination Interface 4.20mm
Circuits (maximum) 4
UL E29179
Current - Maximum per Contact 13.0A
Material - Resin Nylon
Temperature Range - Operating -40? to +105?C
Lock to Mating Part Yes
Pitch - Mating Interface 4.20mm
Color - Resin Natural
CSA LR19980
Polarized to Mating Part Yes
Flammability 94V-2
Package Quantity 1
