This wire gauge is 22-18 AWG with a pink and red color. It is heat shrinkable and has a straight angle. The contact material is copper with tin plating. The insulation type is NiAc and has an insulation diameter of 0.28". The overall length is 1.55" and it has a low-halogen special feature. It can be terminated with butt or crimp type. The wire size includes 18-22 AWG and 22-18 AWG. The maximum voltage is 600V and it has a closed barrel type with red resin color. It is UL and CSA certified with a temperature range of -55? to +125?C.
Wire Gauge (AWG)
22-18
Color
Red
Heat Shrinkable
Yes
Alternate Mfr Part Number
SAA-22-18
Angle
Straight
Contact Material
Copper
Contact Plating
Tin
Family Name
Butt
Insulation Diameter
0.28 "
Insulation Type
NiAc
Overall Length
1.55 "
Plating Material
Tin
Series
19164 Series
Special Features
Low-Halogen
Termination
Butt
Type
Butt Splice
UPC Code
800753113015
Wire Size
18-22 AWG
Wire Size AWG
18, 20, 22
Wire Insulation Diameter
5.46mm max.
Material - Metal
Copper
Material - Plating Termination
Tin
Voltage - Maximum
600V
Barrel Type
Closed
Color - Resin
Red
Insulation
NiAc
CSA
LR18689
UL
E32244
Material - Plating Mating
Tin
Temperature Range - Operating
-55? to +125?C
Package Quantity
1
