Natural Color Cable Connector with 10 Contacts and 5A Rating

Condition: New
Brand: MOLEX
MPN: 09-50-3101
MPN Xref:09-50-3101, MOL09-50-3101, 54H6825, 09503101, 6795094, 6795094P, 9503101, 4546477, 70190788

This Natural color cable connector is a socket housing with low-halogen features. It has 10 contacts, a 5A current rating, and is CSA and UL approved.

Color	Natural
Standards	CSA Certified; UL E29179
Material	Nylon
Connector Type	Receptacle
Hole Center to Center	3.96 mm
Number of Rows	1
Number of Contacts	10
Flammability Rating	UL 94V-2
Package Quantity	1
Agency Approvals	CSA ; UL
Alternate Mfr Part Number	2139-10A
Angle	Straight
Contact Material	Brass/Phosphor Bronze
Current Rating	5 A
Housing Material	Nylon
Operating Temperature	0 to +75 °C
Overall Length	1.556 "
Pin Spacing	0.156 in
Pitch	3.96 mm (0.156")
Primary Type	Cable Connector
Product Header	2139 Series KK® Crimp Terminal Housing
Series	KK 396 Series
Special Features	Low-Halogen
Termination	Crimp
Type	Socket Housing
Voltage Rating	250 V
