Standard .062" Pin and Socket Plug Housing

Standard .062" Pin and Socket Plug Housing

Regular price $0.04 USD
Regular price Sale price $0.04 USD
Sale Sold out
Shipping calculated at checkout.

182 in stock

Condition: New
Brand: Molex
MPN: 03-06-2041
MPN Xref:03-06-2041, 000196, MOLE-0295593, 0003062041, MOLE-0085709, 02N0647, WM1207-ND, MOL03-06-2041, 70190764

This is a Standard 062 Pin and Socket Series plug housing with 4 contacts and a straight body orientation. It has a pitch of 3.68mm and is made of Nylon 6/6 material. The operating temperature range is -40 to +105 °C.
Agency Approvals CSA, UL, TUV
Angle Straight
Color Natural
Current Rating 5 A
Housing Material Nylon 6/6
Mounting Hole Size 0.865×0.312 "
Number of Contacts 4
Number of Rows 1
Operating Temperature -40 to +105 °C
Overall Length 0.75 "
Pin Spacing 0.145 "
Primary Type Soft Shell
Product Header 1625 Series Pin and Socket Plug Housing
Series STANDARD .062"
Termination Crimp
Type Plug
Number Of Contacts 4
Number Of Rows 1
Body Orientation Straight
Pitch 3.68mm
Country of Origin (subject to change) Unknown
