General Purpose Electrolytic Capacitor 22uF 50V Radial
General Purpose Electrolytic Capacitor 22uF 50V Radial
Regular price
$0.10 USD
Regular price
Sale price
$0.10 USD
Unit price
/
per
Shipping calculated at checkout.
104 in stock
Couldn't load pickup availability
Condition: New
Brand: UNITED CHEMI-CON
MPN: EKMG500ELL220ME11D
MPN Xref:EKMG500ELL220ME11D, 565-1337-ND, 23K3675, 1304274, 661-EKMGG500ELL220ME
This is a general purpose electrolytic capacitor with a capacitance of 22 uF and a voltage rating of 50 V. It has a radial termination style and a case diameter of 5 mm. The capacitor is part of the KMG series and has a dissipation factor DF of 0.12. It is suitable for applications requiring a ripple current of 65 mA. The capacitor is available in bulk packaging and has a maximum operating temperature of +105°C.
Parts of this page were generated by an AI
WARNING: Products on this website can expose you to chemicals including Lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
All orders are subject to inventory availability and approval. We are not responsible or liable for errors in the listings.
Brand: UNITED CHEMI-CON
MPN: EKMG500ELL220ME11D
MPN Xref:EKMG500ELL220ME11D, 565-1337-ND, 23K3675, 1304274, 661-EKMGG500ELL220ME
This is a general purpose electrolytic capacitor with a capacitance of 22 uF and a voltage rating of 50 V. It has a radial termination style and a case diameter of 5 mm. The capacitor is part of the KMG series and has a dissipation factor DF of 0.12. It is suitable for applications requiring a ripple current of 65 mA. The capacitor is available in bulk packaging and has a maximum operating temperature of +105°C.
| Capacitance | 22 uF |
| Termination Style | Radial |
| Manufacturer Part No. | EKMG500ELL220ME11D |
| Load Life | 1000 h |
| Case Diameter | 5 mm |
| Lead Spacing | 2 mm |
| Packaging | Bulk |
| Ripple Current | 65 mA |
| Maximum Operating Temperature | + 105 C |
| Series | KMG |
| Dissipation Factor DF | 0.12 |
| Lead Style | Straight |
| Dimensions | 5 mm Dia. x 11 mm L |
| Case Length | 11 mm |
| Voltage Rating DC | 50 V |
| Alternate Part No. | 661-EKMGG500ELL220ME |
| Type | Miniature Aluminum Electrolytic Capacitor |
| Product Category | Aluminium Electrolytic Capacitors - Leaded |
| Product | General Purpose Electrolytic Capacitors |
| Tolerance | - |
| Category | Capacitors |
| Package | - |
| Part Status | ?20% |
| ESR (Equivalent Series Resistance) | 1000 Hrs @ 105?C |
| Lifetime @ Temp. | -55?C ~ 105?C |
| Operating Temperature | Polar |
| Polarization | - |
| Ratings | General Purpose |
| Applications | 0.079" (2.00mm) |
| Size / Dimension | 0.492" (12.50mm) |
| Height - Seated (Max) | - |
| Surface Mount Land Size | Through Hole |
| Mounting Type | Radial, Can |
| Package / Case | 22 ?F |
| Voltage - Rated | 65 mA @ 120 Hz |
| Ripple Current @ Low Frequency | 117 mA @ 100 kHz |
| Applications | General Purpose |
| Capacitance | 22?F |
| Categories | Capacitors |
| ESR (Equivalent Series Resistance) | - |
| Height - Seated (Max) | 0.492" (12.50mm) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Lead Spacing | 0.079" (2.00mm) |
| Lifetime @ Temp. | 1000 Hrs @ 105?C |
| Manufacturer Part Number | EKMG500ELL220ME11D |
| Manufacturer Standard Lead Time | 16 Weeks |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| Mounting Type | Through Hole |
| Operating Temperature | -55?C ~ 105?C |
| Package / Case | Radial, Can |
| Packaging | Bulk Pack |
| Polarization | Polar |
| Ratings | - |
| Ripple Current - High Frequency | 117mA @ 100kHz |
| Ripple Current - Low Frequency | 65mA @ 120Hz |
| Series | KMG |
| Size / Dimension | 0.197" Dia (5.00mm) |
