Low Power Amplifier Integrated Circuit

Condition: New
Brand: Microchip
MPN: MCP6002-I/SN
MPN Xref:MCP6002-I/SN

This integrated circuit is a low power amplifier with a bandwidth of 1MHz and an open-loop gain of 112dB. It has 2 channels and a SMT mounting. The case is SO8 and it has a slew rate of 0.6V/us. The quiescent current is 170uA and it can operate in temperatures ranging from -40C to +85C. The input offset voltage is 4.5mV and it features rail-to-rail operation. It operates at an operating voltage of 1.8 to 5.5V and comes in a SOIC-8 package. It is lead free and RoHS compliant.

Type of integrated circuit	operational amplifier
Bandwidth	1MHz
Open-loop gain	112dB
Mounting	SMT
Number of channels	2
Case	SO8
Slew rate	0.6V/?s
Quiescent current	170?A
Operating temperature	-40...85?C
Input offset voltage	4.5mV
Integrated circuit features	rail-to-rail
Kind of package	tube
Operating voltage	1.8...5.5V
Package/Case	SOIC-8
Product Categories	Op Amps
RoHs Status	Lead free/RoHS Compliant
In-stock	18500
Operating Supply Voltage	1.8 V to 5.5 V
Mounting Style	SMD/SMT
Package / Case	SOIC-8
Slew Rate	0.6 V/us
Shutdown	No
Output Current	23 mA
Maximum Operating Temperature	+ 85 C
Packaging	Tube
Amplifier Type	Low Power Amplifier
Gain Bandwidth Product	1 MHz
Minimum Operating Temperature	- 40 C
Factory Pack Quantity	100
Supply Current	0.1 mA
Technology	CMOS
Voltage Gain dB	112 dB
