Tactile & Jog Switch, SPST, 24V DC, Through Hole, Non-Illuminated, Bulk Packaging

Condition: New
Brand: TE CONNECTIVITY / ALCOSWITCH
MPN: FSMRA4JH04
MPN Xref:FSMRA4JH04, 506-FSMRA4JH04, 40P4336, 1795331, 1813692, 70156202

This Tactile & Jog Switch is a SPST non-illuminated button switch with a voltage rating of 24V DC. It has a mounting style of Through Hole and a termination style of Solder Pin.

Product Categories	Tactile & Jog Switches
RoHs Status	Rohs
In-stock	671
Voltage Rating DC	24 V
Ground Terminal	No
Contact Form	SPST
Switch Function	OFF - (ON)
Mounting Style	Through Hole
Illumination	Non-Illuminated
Packaging	Bulk
Termination Style	Solder Pin
Part # Aliases	1-1825027-1
Switch Operation	Momentary
Maximum Operating Temperature	+85°C
Width	7.01mm
Minimum Operating Temperature	-35°C
Length	7.11mm
Actuator Type	Button
Mechanical Life	100000Cycles
Brand	TE Connectivity
Contact Current Rating	50 mA
Operating Temperature Range	-35 ? +85°C
Actuator Length	5.74mm
Mounting Type	PCB Mount
Dimensions	7.11 x 7.01mm
Actuator Colour	Black
Contact Configuration	Single Pole Single Throw (SPST)
Operating Force	Operating Force
Voltage Rating	24 V
Contact Material	Contact Material
Terminal Type	Terminal Type
Stock	Stock
Alternate Mfr Part Number	1-1825027-1
Current Rating	50 mA
Mounting Hole Size	0.039 in
Operation	Off (On)
Series	FSM Series
Termination	PCB Pins
Type	Tactile
Package Quantity	1
