AMP 0.062 Socket Contact - 794016-1
AMP 0.062 Socket Contact - 794016-1
Regular price
$0.01 USD
Regular price
Sale price
$0.01 USD
Unit price
/
per
Shipping calculated at checkout.
71 in stock
Couldn't load pickup availability
Condition: New
Brand: AMP - TE CONNECTIVITY
MPN: 794016-1
MPN Xref:794016-1, 1913797, 7940161, 74114997696, AMP794016-1, 7190501, 571-7940161, A14049-ND, 1863471
This socket contact is designed for use with AMP 0.062 Soft-Shell Connectors. It has a current rating of 8A and an operating voltage of 250. The contact is made of brass with a pre-tin plating.
Parts of this page were generated by an AI
WARNING: Products on this website can expose you to chemicals including Lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
All orders are subject to inventory availability and approval. We are not responsible or liable for errors in the listings.
Brand: AMP - TE CONNECTIVITY
MPN: 794016-1
MPN Xref:794016-1, 1913797, 7940161, 74114997696, AMP794016-1, 7190501, 571-7940161, A14049-ND, 1863471
This socket contact is designed for use with AMP 0.062 Soft-Shell Connectors. It has a current rating of 8A and an operating voltage of 250. The contact is made of brass with a pre-tin plating.
| Country of Origin (subject to change) | United States |
| Alternate Mfr Part Number | 794016-1 |
| Contact Plating | Pre-Tin Over Brass |
| Contact Type | Socket |
| Current Rating | 8 A |
| For Use With | AMP 0.062 Soft-Shell Connectors |
| Primary Type | Contact |
| Series | Standard .062 Series |
| Termination | Crimp |
| Type | Socket |
| Wire Size | 18-24 AWG |
| Product Type | Contact |
| Operating Voltage | 250 |
| Connector System | Wire-to-Wire |
| Connector | Wire & Cable |
| Contact Current Rating (Max) | 9 |
| Contact Retention Within Housing | With |
| Contact Base Material | Brass |
| Contact Mating Area Plating Material | Pre-Tin |
| Contact Termination Area Plating Material | Pre-Tin |
| Wire Contact Termination Area Plating Material | Pre-Tin |
| Contact Orientation | Straight |
| Termination Type | Crimp |
| Connector Mounting Type | Cable Mount (Free-Hanging) |
| Wire Insulation Support | Without |
| Mating Pin Diameter | 1.57 mm [ .062 in ] |
| Accepts Wire Insulation Diameter Range | 1.27 ? 2.79 mm [ .05 ? .11 in ] |
| Operating Temperature Range | -55 ? 105 ?C [ -67 ? 221 ?F ] |
| Circuit Application | Power |
| For Multiple Crimp | No |
| Glow Wire Rating | Standard Part - Not Glow Wire |
| Packaging Method | Bag |
| Categories | Connectors, Interconnects |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
| Contact Termination | Crimp |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Manufacturer Part Number | 794016-1 |
| Manufacturer Standard Lead Time | 7 Weeks |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Packaging | Bulk Pack |
| Pin or Socket | Socket |
| Series | Commercial .062" Pin and Socket |
| Standard Package | 1,000 |
| Type | - |
| Wire Gauge | 18-24 AWG |
| Alternate Parts | 350628-1 350628-8 |
