CONN QC RCPT 16-20AWG 0.187

Condition: New
Brand: TE Connectivity AMP Connectors
MPN: 42617-1
MPN Xref:42617-1, 426171, AMP42617-1, E5329833, A27715CT-ND, A27715TR-ND, 571-42617-1, 74114997591, 42617-1**MULT1

0.187" (4.75mm) Quick Connect Female 16-20 AWG Crimp Connector Non-Insulated

Manufacturer Product Number	42617-1
Description	CONN QC RCPT 16-20AWG 0.187
Manufacturer Standard Lead Time	11 Weeks
Detailed Description	0.187" (4.75mm) Quick Connect Female 16-20 AWG Crimp Connector Non-Insulated
Category	Connectors, Interconnects
Series	Faston
Package	Tape & Reel (TR)
Product Status	Active
Terminal Type	Receptacle
Gender	Female
Tab Width	0.187" (4.75mm)
Tab Thickness	0.020" (0.51mm)
Tab Length	0.250" (6.35mm)
Length - Overall	0.585" (14.86mm)
Termination	Crimp
Wire Gauge	16-20 AWG
Insulation	Non-Insulated
Mounting Type	Free Hanging (In-Line)
Features	-
Color	-
Contact Material	Brass
Contact Finish	-
Insulation Diameter	0.090" ~ 0.130" (2.29mm ~ 3.30mm)
Base Product Number	42617
Part Status	Active
Terminal	Receptacle
Wire Size	.51 ? 1.31
Mating Tab Width	4.75 mm [ .187 in ]
Mating Tab Thickness	.51 mm [ .02 in ]
Terminates To	Wire & Cable
Insertion Force	Normal
Sealable	No
Insulated	No
Wire/Cable Type	Regular Wire
Wire Stop	No
Connection Capacity	Single
Fully Insulated	No
Plating Material	Unplated
Terminal Orientation	Straight
Contact Base Material	Brass
Crimp Type	F-Crimp
Barrel Type	Open
Wire Insulation Support	With
Mating Retention Type	Dimple
Receptacle Terminal Stock Thickness	.3 mm [ .012 in ]
Overall Length	14.86 mm [ .585 in ]
Accepts Wire Insulation Diameter Range	2.29 ? 3.3 mm [ .09 ? .13 in ]
Operating Temperature Range	-40 ? 110 ?C [ -40 ? 230 ?F ]
CSA Certified	Yes
UL Rating	Listed
Packaging Method	Strip/Reel
Packaging Quantity	20000
Line	Budget
