Tactile Switch SPST-NO 0.05A 24V

Condition: New
Brand: TE CONNECTIV
MPN: 1-1825027-4
MPN Xref:1-1825027-4, AMP1-1825027-4, E5225827, 46Y9109, 450-1659-ND, 118250274, 2468742

This is a round tactile switch with a single pole-single throw configuration. It has a contact rating of 50mA at 24VDC and an operating force of 160gf. The switch is made of polyamide (PA) and nylon material with an ivory actuator color and a black case color. It is suitable for through-hole mounting with a right-angle orientation. The switch has a height of 7mm and a button width of 3.2mm. It is dust-proof and illuminated with a tactile feel. The switch is supported by a bracket and has a ganged feature.

Actuator Style	Round
Operating Function	NO
Contact Base Material	Copper Alloy
Switch Contact Plating Material	Silver
Dust Proof	No
Illuminated	With
Leg Style	Kinked
Product Type	Switch
Snap Action	Without
Tactile	Yes
Support Bracket	With
Configuration (Pole-Throw)	Single Pole - Single Throw
Number of Actuators	1
Ganged	With
ESD Grounding Terminal	Without
Tactile Feel	With
Actuator Material	0.25mm
Actuator Profile	Extended
Bushing Style	Unthreaded
Case Material	Nylon
Actuator Color	Ivory
Actuator Force	160 g [ 5.648 oz ]
Case Color	Black
Contact Current Rating	50
Termination Type	Printed Circuit Board
Mounting Type	-
Mounting Angle	With
Low Profile	With
Process Sealed	No
Switch Height	7 mm [ .276 in ]
Button Width	3.2 mm [ .126 in ]
Actuator Length	3.56 mm [ .14 in ]
Temperature Rating	Standard
Packaging Method	Loose Piece
Comment	(On) indicates momentary position.
Actuator Height off PCB, Vertical	-
Actuator Length, Right Angle	6.15mm
Actuator Material	Polyamide (PA), Nylon
Actuator Orientation	Side Actuated
Actuator Type	Standard
Categories	Switches
Circuit	SPST-NO
Contact Rating @ Voltage	0.05A @ 24VDC
Features	-
Illumination	Non-Illuminated
Illumination Type, Color	-
Illumination Voltage (Nominal)	-
Ingress Protection	-
Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Manufacturer Part Number	1-1825027-4
Manufacturer Standard Lead Time	11 Weeks
Mechanical Life	100,000 Cycles
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mounting Type	Through Hole, Right Angle
Operating Force	160gf
Operating Temperature	-35?C ~ 85?C
Type of switch	microswitch TACT
Contacts configuration	SPST-NO
Number of positions	2
DC contacts rating @R	50mA / 24V DC
Mounting	THT
Illumination	-
Switching method	OFF-(ON)
Operating temperature	-35...85?C
Button shape	round
Key button colour	white
Leads	for PCB
Contact material	copper
Max. contact resistance:	100m?
Contact plating	silver plated
Manufacturer series	FSMRAJ
Body colour	black
Shape	square
Stable positions number	1
Category	Switches
Series	FSMRAJ
Package	Active
Part Status	SPST-NO
Circuit	SPST-NO
Switch Function	0.05A @ 24VDC
Contact Rating @ Voltage	Standard
Actuator Type	Standard
Actuator Height off PCB, Vertical	-
Actuator Length, Right Angle	6.15mm
Actuator Orientation	PC Pin
Termination Style	PC Pin
Outline	Non-Illuminated
Illumination Type, Color	-
Illumination Voltage (Nominal)	-
Operating Force	-
Ingress Protection	-
Features	-
Operating Temperature	Polyamide (PA), Nylon
Switch Travel	100,000 Cycles
Alternate Mfr Part Number	1-1825027-4
Country of Origin (subject to change)	Korea, Republic of
Manufacturer Product Number	1-1825027-4
Description	SWITCH TACTILE SPST-NO 0.05A 24V
Manufacturer Standard Lead Time	22 Weeks
Detailed Description	Tactile Switch SPST-NO Side Actuated Through Hole, Right Angle
Product Status	Active
Mechanical Life	100,000 Cycles
Base Product Number	1825027
