THUMBWHEEL POT 1K OHM 0.5W TOP - Trimmer Resistors - Single Turn
Part Status
Active
Power (Watts)
0.5W, 1/2W
Tolerance
?20%
Size / Dimension
Round - 0.350" Dia x 0.210" H (8.89mm x 5.33mm)
Termination
Solderable Pins
Mounting Type
Through Hole
Number of Turns
1
Resistance
1k?
Manufacturer Product Number
3352P-1-102LF
Description
THUMBWHEEL POT 1K OHM 0.5W TOP
Manufacturer Standard Lead Time
11 Weeks
Category
Potentiometers, Variable Resistors
Series
Trimpot? 3352 - Open Frame
Package
Bulk
Product Status
Active
Base Product Number
3352P
Stock
Power Rating
0.5 W
Manufacturer Part No.
3352P-1-102LF
Product
Trimmer Resistors - Single Turn
Packaging
Tube
Product Type
Single Turn
Voltage Rating
250 V
Alternate Part No.
652-3352P-1-102LF
Tradename
Trimpot
Product Category
Trimmer Resistors - Through Hole
Element Type
Cermet
Termination Style
Radial
Operating Temperature Range
- 55 C to + 125 C
Taper
Linear
Temperature Coefficient
±150 ppm/°C
Type of potentiometer
mounting
Kind of potentiometer
horizontal,
Power
0.5W
Mounting
THT
Characteristics
linear
Track material
cermet
Operating temperature
-55...125?C
Body dimensions
9.5x9x3.8mm
Terminal pitch
5.08x2.54mm
Max. operating voltage
250V
Electrical rotation angle
205?
Dielectric Strength
500 VAC
Dimensions
0.35 Dia. x 0.15 H in
Element Material
Cermet
Maximum Operating Temperature
+125 °C
Mechanical Angle
250 °
Minimum Operating Temperature
-55 °C
Primary Type
Trimmers
Rotational Life
200 Cycles
Torque
3 oz/in
