CAP ALUM 4.7UF 20% 25V SMD - S Series
CAP ALUM 4.7UF 20% 25V SMD - S Series
Regular price
$0.04 USD
Regular price
Sale price
$0.04 USD
Unit price
/
per
Shipping calculated at checkout.
30 in stock
Couldn't load pickup availability
Condition: New
Brand: Panasonic
MPN: EEE-1EA4R7SR
MPN Xref:EEE-1EA4R7SR, 5369916, 9696954, EEE-1EA4R7SR/BKN, 70068007, PCE3910DKR-ND, PANA-0062820, PCE3910CT-ND, 96K9432
This is a description for the CAP ALUM 4.7UF 20% 25V SMD capacitor from the S Series. It has a capacitance of 4.7 uF and a voltage rating of 25V. The capacitor is polarized and has a tolerance of ?20%. It is suitable for automotive applications and is RoHS compliant. The dimensions are 0.157" Dia (4.00mm) and 0.213" (5.40mm) height.
Parts of this page were generated by an AI
WARNING: Products on this website can expose you to chemicals including Lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
All orders are subject to inventory availability and approval. We are not responsible or liable for errors in the listings.
Brand: Panasonic
MPN: EEE-1EA4R7SR
MPN Xref:EEE-1EA4R7SR, 5369916, 9696954, EEE-1EA4R7SR/BKN, 70068007, PCE3910DKR-ND, PANA-0062820, PCE3910CT-ND, 96K9432
This is a description for the CAP ALUM 4.7UF 20% 25V SMD capacitor from the S Series. It has a capacitance of 4.7 uF and a voltage rating of 25V. The capacitor is polarized and has a tolerance of ?20%. It is suitable for automotive applications and is RoHS compliant. The dimensions are 0.157" Dia (4.00mm) and 0.213" (5.40mm) height.
| Applications | |
| Capacitance | 4.7 ?F |
| Height - Seated (Max) | 0.213" (5.40mm) |
| Lead Free Status / RoHS Status | RoHS Compliant |
| Lifetime @ Temp. | 2000 Hrs @ 85 |
| Manufacturer Part Number | EEE-1EA4R7SR |
| Manufacturer Standard Lead Time | 21 Weeks |
| Mounting Type | Surface Mount |
| Operating Temperature | -40 |
| Package / Case | Radial, Can - SMD |
| Packaging | Reel |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Ripple Current - High Frequency | 37.4mA @ 10kHz |
| Ripple Current - Low Frequency | 22mA @ 120Hz |
| Series | S Series |
| Size / Dimension | 0.157" Dia (4.00mm) |
| Standard Package | 2,000 |
| Surface Mount Land Size | 0.169" L x 0.169" W (4.30mm x 4.30mm) |
| Tolerance | |
| Voltage - Rated | 25V |
| Category | Capacitors |
| Package | Tape & Reel (TR) |
| Product Status | Not For New Designs |
| ESR (Equivalent Series Resistance) | - |
| Ripple Current @ Low Frequency | 22 mA @ 120 Hz |
| Ripple Current @ High Frequency | 37.4 mA @ 10 kHz |
| Lead Spacing | - |
| Base Product Number | EEE-1EA |
| Capacitance Range | 1 to 99 uF |
| Case Code | B |
| Case Size | Dia. 0.157 x L 0.217 in ; Dia. 4 x L 5.5 mm |
| Configuration | Radial ; Can |
| Dimensions | 0.157 Dia. x 0.217 L ; 4 Dia. x 5.5 L in ; mm |
| Element Material | Aluminum Electrolytic |
| Maximum Operating Temperature | 85 C |
| Minimum Operating Temperature | -40 C |
| Special Features | Automotive |
| Termination | SMD |
| Voltage Rating | 25 VDC |
| Manufacturer Product Number | EEE-1EA4R7SR |
| Description | CAP ALUM 4.7UF 20% 25V SMD |
| Detailed Description | 4.7 ?F 25 V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 85?C |
