UVY2V100MPD Aluminum Electrolytic Capacitor - 10uF, 350V, Radial Can
UVY2V100MPD Aluminum Electrolytic Capacitor - 10uF, 350V, Radial Can
Regular price
$0.10 USD
Regular price
Sale price
$0.10 USD
Unit price
/
per
Shipping calculated at checkout.
Low stock: 10 left
Couldn't load pickup availability
Condition: New
Brand: Nichicon
MPN: UVY2V100MPD
MPN Xref:UVY2V100MPD, UVY2V100MPD-ND, 70188059
This is a description of the capacitor product UVY2V100MPD. It is an aluminum electrolytic capacitor with a capacitance of 10uF, voltage rating of 350V, and a radial can package.
Parts of this page were generated by an AI
WARNING: Products on this website can expose you to chemicals including Lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
All orders are subject to inventory availability and approval. We are not responsible or liable for errors in the listings.
Brand: Nichicon
MPN: UVY2V100MPD
MPN Xref:UVY2V100MPD, UVY2V100MPD-ND, 70188059
This is a description of the capacitor product UVY2V100MPD. It is an aluminum electrolytic capacitor with a capacitance of 10uF, voltage rating of 350V, and a radial can package.
| Applications | |
| Capacitance | 10?F |
| ESR (Equivalent Series Resistance) | - |
| Height - Seated (Max) | 0.551" (14.00mm) |
| Lead Free Status / RoHS Status | RoHS Compliant |
| Lead Spacing | 0.197" (5.00mm) |
| Lifetime @ Temp. | 2000 Hrs @ 105?C |
| Manufacturer Part Number | UVY2V100MPD |
| Manufacturer Standard Lead Time | 18 Weeks |
| Mounting Type | PCB Mount |
| Operating Temperature | -40?C ~ 105?C |
| Package / Case | Radial, Can |
| Packaging | Bulk Pack |
| Polarization | Polar |
| Ratings | - |
| Ripple Current - High Frequency | 102.4mA @ 10kHz |
| Ripple Current - Low Frequency | 64mA @ 120Hz |
| Series | UVY |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Standard Package | 200 |
| Surface Mount Land Size | - |
| Tolerance | |
| Voltage - Rated | 350V |
| Type of capacitor | electrolytic |
| Mounting | THT |
| Operating voltage | 350V DC |
| Body dimensions | ?10x12.5mm |
| Terminal pitch | 5mm |
| Service life | 1000h |
| Operating temperature | -55...105?C |
| Capacitors series | UVY |
| Operating current | 64mA |
| Part Number | UVY2V100MPD |
| Batteries Required? | No |
| ASIN | B00DWIJDQO |
| Manufacturer Product Number | UVY2V100MPD |
| Description | CAP ALUM 10UF 20% 350V RADIAL |
| Detailed Description | 10 ?F 350 V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105?C |
| Category | Capacitors |
| Package | Bulk |
| Product Status | Not For New Designs |
| Ripple Current @ Low Frequency | 64 mA @ 120 Hz |
| Ripple Current @ High Frequency | 73.6 mA @ 10 kHz |
| Base Product Number | UVY2V |
| Capacitance Range | 1 to 99 uF |
| Case Size | Dia. 0.394 x L 0.492 in ; Dia. 10 x L 12.5 mm |
| Configuration | Radial ; Can |
| Element Material | Aluminum Electrolytic |
| Minimum Operating Temperature | -40 C |
| Termination | Through Hole |
| Voltage Rating | 350 VDC |
