Male Tab Quick Disconnect - Brass with Zinc Chromate Plating

Male Tab Quick Disconnect - Brass with Zinc Chromate Plating

Regular price $0.05 USD
Regular price Sale price $0.05 USD
Sale Sold out
Shipping calculated at checkout.

Low stock: 5 left

Condition: New
Brand: MOLEX
MPN: 19004-0001
MPN Xref:19004-0001, WM18761-ND, 70111033, 538-19004-0001, 0190040001, 489723, 190040001, MOL19004-0001, 78068798526

This male tab quick disconnect is made of brass with zinc chromate plating, nylon insulation, and a red resin color. It is suitable for wire sizes 18-22 AWG with a maximum insulation diameter of 3.68mm. The tab width is 6.35mm and the tab thickness is 0.81mm. It has a temperature range of -65 to +105°C and a maximum voltage rating of 600V.
Barrel Type Closed
Wire Size AWG 18, 20, 22
Wire Insulation Diameter 3.68mm max.
Tab Width 6.35mm
Temperature Range - Operating -65? to +105?C
Material - Plating Mating Zinc Chromate
Material - Resin Nylon
Color - Resin Red
Insulation Nylon (PA)
Material - Plating Termination Zinc Chromate
Plating min - Mating 5.080?m
Plating min - Termination 5.080?m
UL E79133
Orientation Straight
Tab Thickness 0.81mm
Flammability 94V-2
Voltage - Maximum 600V
Material - Metal Brass
Gender Male
CSA LR18689
Package Quantity 1
Alternate Mfr Part Number AA-2260
Angle Straight
Color Red
Contact Material Brass
Contact Plating Zinc Chromate
Family Name InsulKrimp
Insulation Type Nylon
Plating Material Zinc Chromate
Series 19004 Series
Special Features Low-Halogen
Type Male Tab Quick Disconnect
UPC Code 800753030008
Wire Size 18-22 AWG
