1619 Series Pin and Socket Receptacle Housing

Condition: New
Brand: MOLEX
MPN: 03-09-1011
MPN Xref:03-09-1011, WM1302-ND, 9731490, 1960038, 9629, 54H5148, 0003091011, 70190837, 538-03-09-1011

This is a 2-position socket receptacle housing with a pitch of 5.03mm and a voltage rating of 250V.

Color	Natural
Agency Approvals	CSA ; UL ; TUV
Alternate Mfr Part Number	1619-1R1B5N1A5
Angle	Straight
Current Rating	14 A
Housing Material	Nylon 6/6
Number of Circuits	1 to 15
Number of Contacts	1
Number of Rows	1,1
Operating Temperature	-40 to +105 °C
Overall Length	1.03 "
Pin Spacing	0.198 in
Pitch	5.03mm
Primary Type	Soft Shell
Product Header	1619 Series Pin and Socket Receptacle Housing
Series	Standard 093 Pin and Socket Series
Special Features	Low-Halogen
Termination	Crimp
Type	Socket
Voltage Rating	250 V
Hole Center to Center	5.03 mm
Connector Type	Receptacle
Material	Nylon
Standards	CSA Certified; UL E29179
Max. Temp.	105?C
Flammability Rating	UL 94V-2
Package Quantity	1
