6A 125V AC Time Delay Glass Fuse

6A 125V AC Time Delay Glass Fuse

Regular price $0.22 USD
Regular price Sale price $0.22 USD
Sale Sold out
Shipping calculated at checkout.

56 in stock

Condition: New
Brand: Bussmann
MPN Xref:GMC-6-R, GMC-6-R-ND, GR0101787, 48K9597, BK/GMC-6-R, G2467473, 1CK13, 504-BK/GMC-6-R, 1375511

This fuse has an amp rating of 6A and a voltage rating of 125V AC. It has a cylindrical glass body and is a time delay fuse. It has an interrupt rating of 10 kA at 125V AC and is compatible with nonrejection fuse block styles. The fuse is 20mm in length and 5mm in diameter. It is CE, UL, and CSA certified.
Country of Origin CN
UNSPSC 39121607
Standard UL 248-14, CSA, CE
Application Electronic Circuits
Element Single
Fuse Interrupt Rating 10 at 250 V ac kA
Fuse Type Time Delay Fuse
Fuse Dimension 0.788 L x 0.197 in. Dia.
Rated Voltage 125V ac
Response Time 2 Maximum at 200 Percent Rated Amps min; 60 Maximum at 135 Percent Rated Amps min
Fuse Amps 6A
Manufacturer Part Number GMC-6-R
Item Number GMC-6-R
Product Series GMC
Material Glass
Current Rating 6 A
Voltage (AC) 125 VAC
Characteristic Time Delay
Package Type Cartridge
Trip Indicator No
Alarm Contact No
Length (mm) 20.32 mm
Diameter (mm) 5 mm
Diameter (in) 0.2 "
Approvals CSA, UL
RoHS Yes
Length (In) 0.8 "
Net Weight 0.005 lbs
Gross Weight 16 lbs
Amps 6 A
Diameter 5 mm
Length 20 mm
Opening Medium Time-Delay
Mounting Cartridge
Volts AC 125
Class Miniature
Interrupt Rating AC 10 kA
Item Fuse
AC Voltage Rating 125V AC
Series GMC
Speed Time Delay
Fits Fuse Block Style Nonrejection
Fuse Size 20mm L x 5mm dia
Equivalent Series 239, GMC, GSC
Compatible Fuse Block Series HTB
Standards CE, UL 248-14 Guide JDYX, CSA Certification Class 1422-01
DC Voltage Rating Not Rated
Visual Indication Glass Fuse
Body Style Cylindrical
Interrupt Rating 10kA at 125V AC
Body Material Glass
Catalog Number GMC-6-R
Made in USA No
Connection Ferrule End X Ferrule End
Special Features Low Breaking Capacity, Interrupt Rating 10000 Amp at 125 Vac, Material Glass Tube, Nickel Plated Brass Endcap, ROHS Compliant
UPC 051712643016
Item Type Electronic, Medium Time Delay
Size 5.20 mm Diameter X 20.00 mm Height
Voltage Rating 125 Vac
Category Glass Body Fuses
Amperage Rating: 6 A
Size: 5.20 mm Diameter X 20.00 mm Height
Type: Electronic, Medium Time Delay
Voltage Rating: 125 VAC
Connection: Ferrule End X Ferrule End
Response Time: 120/3.6k s
Standard: UL 248-14, CSA, CE
Fuse Holder Code E
Fuse Speed Time Delay
Functionally Equal To Littelfuse 239, Mersen/Ferraz Shawmut GSC
Fuse Voltage Rating 125VAC
In Line Fuseholder E
Rejection / Nonrejection Nonrejection
Green Environmental Attribute RoHS 2011/65/EU Compliant
Indicating / Nonindicating Indicating
Length (Straight Wireway) 20 mm
Country of Origin (subject to change) China
Alternate Mfr Part Number GMC-6-R
