General Purpose Electrolytic Capacitor - 22uF 25V

Condition: New
Brand: UNITED CHEMI-CON
MPN: EKMG250ELL220ME11D
MPN Xref:EKMG250ELL220ME11D, 23K3609, 565-1304-ND, 661-EKMGG250ELL220ME, 1686777

This aluminum electrolytic capacitor is ideal for general purpose applications with its 22uF capacitance and 25V voltage rating.

Dimensions	5 mm Dia. x 11 mm L
Voltage Rating DC	25 V
Maximum Operating Temperature	+ 105 C
Series	KMG
Manufacturer Part No.	EKMG250ELL220ME11D
Packaging	Bulk
Tolerance
Capacitance	22 uF
Case Diameter	5 mm
Product Category	Aluminium Electrolytic Capacitors - Leaded
Alternate Part No.	661-EKMGG250ELL220ME
Case Length	11 mm
Product	General Purpose Electrolytic Capacitors
Termination Style	Radial
Category	Capacitors
Package	Active
Part Status	?20%
ESR (Equivalent Series Resistance)	1000 Hrs @ 105?C
Lifetime @ Temp.	1000 Hrs @ 105
Operating Temperature	Polar
Polarization	-
Ratings	General Purpose
Applications
Lead Spacing	0.197"" Dia (5.00mm)
Size / Dimension	0.197" Dia (5.00mm)
Height - Seated (Max)	-
Surface Mount Land Size	Through Hole
Mounting Type	Radial, Can
Package / Case	Radial, Can
Voltage - Rated	54mA @ 120Hz
Ripple Current @ Low Frequency	97.2mA @ 100kHz
Manufacturer Part Number	EKMG250ELL220ME11D
Manufacturer Standard Lead Time	16 Weeks
Ripple Current - High Frequency	97.2mA @ 100kHz
Ripple Current - Low Frequency	54mA @ 120Hz
RoHS Status	ROHS3 Compliant
Standard Package	3,000
