Polymeric PCB Mounted Fuse - 40A, 30V

Condition: New
Brand: BOURNS
MPN: MF-R090-0-9
MPN Xref:MF-R090-0-9, 70153585, 6478500, MFR09009, MF-R090-0-9-ND, 1652182, BOUR-0017299, 652-MF-R090-0-9, 742503

This polymeric PCB mounted fuse is perfect for protecting low voltage power supplies and loads. It has a maximum current rating of 40A and a maximum voltage rating of 30V.

Current - Hold (Ih) (Max)	900mA
Current - Max	40A
Current - Trip (It)	1.8A
Height - Seated (Max)	0.480" (12.20mm)
Lead Free Status / RoHS Status	RoHS Compliant
Lead Spacing	0.201" (5.10mm)
Manufacturer Part Number	MF-R090-0-9
Manufacturer Standard Lead Time	5 Weeks
Mounting Type	PCB Mount
Operating Temperature	-40
Package / Case	Radial, Disc
Packaging	Bulk Pack
Resistance - Initial (Ri) (Min)	70 mOhms
Resistance - Post Trip (R1) (Max)	220 mOhms
Series	MF-R Series
Size / Dimension	0.291" L x 0.118" W (7.40mm x 3.00mm)
Standard Package	500
Time to Trip	5.9s
Type	Polymeric
Voltage - Max	30V
Alternate Parts
Application	Almost anywhere there is a low Voltage power Supply and a load to be protected, including computers and peripherals, general electronics and automotive applications
Body Material	Epoxy Polymer
Current Rating	40 A
DC Resistance	0.07 Ohms
Dimensions	0.291 x 0.118 in
Holding Current	0.9 A
Maximum Operating Temperature	85 °C
Minimum Operating Temperature	-40 °C
Primary Type	Resettable Fuses
Resistance	0.07 Ohms
Standards	UL Recognized, CSA Certified, TUV Certified
Termination	PCB ; Radial Leads
Voltage Rating	30 V
