Conformal Coated RF Choke - 100uH, 550mA, Ferrite Core

Conformal Coated RF Choke - 100uH, 550mA, Ferrite Core

Regular price $0.42 USD
Regular price Sale price $0.42 USD
Sale Sold out
Shipping calculated at checkout.

25 in stock

Condition: New
Brand: Bourns
MPN: 5300-25-TR-RC
MPN Xref:5300-25-TR-RC, 5300-25-TR-RC-ND, 652-5300-25-TR-RC

This conformal coated RF choke is made with ferrite core material for high inductance and low resistance. It has a maximum DC current of 550mA and is RoHS compliant.
Current - Saturation 300mA
Current Rating (Amps) 550mA
DC Resistance (DCR) 670mOhm Max
Frequency - Self Resonant 3.9MHz
Inductance 100 ?H
Inductance Frequency - Test 1kHz
Lead Free Status / RoHS Status RoHS Compliant
Manufacturer Part Number 5300-25-TR-RC
Manufacturer Standard Lead Time 16 Weeks
Material - Core Ferrite
Mounting Type Through Hole
Operating Temperature -55
Package / Case Axial
Packaging Reel
Series 5300
Shielding Unshielded
Size / Dimension 0.160" Dia x 0.500" L (4.06mm x 12.70mm)
Standard Package 3,000
Type Conformal Coated RF Chokes
Alternate Parts
Self Resonant Frequency 3.9 MHz
Product Chokes
Alternate Part No. 652-5300-25-TR-RC
Test Frequency 1 kHz
Brand J.W. Miller
Manufacturer Part No. 5300-25-TR-RC
Product Category Fixed Inductors
Maximum DC Resistance 670 mOhms
Termination Style Axial
Operating Temperature Range - 55 C to + 105 C
Maximum DC Current 550 mA
Category Inductors, Coils, Chokes
Package Tape & Reel (TR)
Product Status Active
Current - Saturation (Isat) 300mA
Q @ Freq -
Ratings -
Supplier Device Package -
Height - Seated (Max) -
Base Product Number 5300
Part Status Active
